| Specification: |
|
| ▪ Display |
: 10" Colour touchsreen |
| ▪ Detector wide range |
: 190-930nm |
| ▪ Operate |
: Easy to operate GUI (Graphical User Interface) |
| |
: Automatic gas box for easy changeover from Air to N2O |
| |
: Push button ignition |
| |
: Emergency gas shut-off in case of flame outage |
| ▪ Port USB |
: 4 USB port for Printer, mouse and keyboard |
| ▪ Wavelength adjustment |
: 3 digit motor driven, |
| |
0 to 1000nm +0.1 nm |
| ▪ Reproducibility |
: +0.1 nm |
| ▪ Resolution |
: variable slit - 2Å, 7Å, and 20Å |
| ▪ Operating Modes |
: |
| Absorbance/Emission |
: -0.0820 to 3.2000 |
| Concentration |
: to 5 significant digits |
| Integration Period |
: 0.1 to 99.9 seconds |
| Screen Refresh |
: 0.224, 0.448 or 0.896 seconds |
| Recorder Output |
: 1V/ABS (-0.08 to 3.2V) |
| Background Correction |
: In-line Deuterium Arc |
| ▪ Hollow Cathode Lamps |
: |
| Dimension |
1.5" OD |
| Striking Voltage |
: 500V |
| Lamp Current |
: 0 to 18 mA average current |
| |
(typical current is 1.5-8.0 mA) |
| ▪ Burner Assembly: |
|
| Design |
: Polyethylene Pre-mix chamber, |
| |
: glass impact bead dispersion |
| Burner Head |
: Titanium; air-acetylene head - 4" x 0.026" single slot |
| |
: (nitrous oxide head - 2" x 0.019" single slot) |
| Adjustments |
: Horizontal and Vertical positioning |
| ▪ Performance: |
|
| Average Noise (at 3 ) |
: 0.0018 ABS (Cu at 324.7nm, 7Å slit, 5 sec. int.) |
| Acessories |
|
| 1. Hollow Cathode Lamps |
: As, Cu, Hg, Pb, Ag, Fe, Mn, Cd, Cr, Se, Al, Zn |
| 2. Standards Solution |
: @125ml for : As, Cu, Hg, Pb, Ag, Fe, Mn, Cd, Cr, Se, Al, Zn |
