| Spesifikasi : |
|
|
| a. Parameter yang diukur |
|
|
| Parameter |
Range |
Jumlah |
| ▪ Iron |
: 0-30 mg/l |
50 test |
| ▪ Ammonia |
: 0-1 mg/l |
50 test |
| ▪ Ammonia |
: 1-50 mg/l |
50 test |
| ▪ Phospate |
: 0-80 mg/l |
50 test |
| ▪ Nitrat |
: 0.00-11.00 mg/l |
50 test |
| ▪ Nitrit |
: 0-1500 mg/l |
50 test |
| ▪ Sulfat |
: 5-100 mg/l |
50 test |
| ▪ Klorida |
: 0.5-25 mg/l |
50 test |
| ▪ TSS |
: 0-750 mg/l |
50 test |
| ▪ COD |
: 0-150mg/l |
50 test |
| ▪ COD |
: 0-1.500 mg/l |
50 test |
| ▪ Turbidity |
: 0-1100 NTU |
Tidak terbatas |
| ▪ pH Range |
: -2.00-20.00 pH |
Tidak terbatas |
| ▪ Temperatur |
: 0-105 °C |
Tidak terbatas |
| ▪ BOD Range |
: 0-4000 mg/l |
Tidak terbatas |
| ▪ TSS |
: 0 - 20,000 mg/l |
Tidak terbatas |
| ▪ Bau |
: 0-999 µg/m3 |
Tidak terbatas |
| ▪ Kecepatan air |
: 0,5 - 2,5 m/detik |
Tidak terbatas |
| |
|
|
| b. Photometer |
|
|
| ▪ Wavelength |
: 7 channel |
|
| |
: 380nm, 420nm, 490nm, 575nm, |
| |
585nm, 650nm, 750nm |
|
| ▪ Koneksi Data |
: Bluetooth |
|
| ▪ Kalibrasi |
: Otomatis dengan sensor warna untuk |
| |
penentuan Kecerahan Sinar |
| ▪ Menetralkan Alat |
: Fungsi OTZ |
|
| |
dapat mendeteksi tipe nol yg berbeda |
| ▪ Memori |
: Dapat menyimpan 100 data |
| ▪ Jam / Tanggal |
: Ada pada layar monitor |
|
| ▪ Tombol |
: Terdiri dari 4 tombol dalam pengaturan |
| ▪ Sumber Tenaga |
: 4 x 1.5 V AAA |
|
| ▪ Layar |
: Layar LCD , monochrome |
|
| ▪ Pilihan Bahasa |
: Jerman, Inggris, Spanyol, Perancis |
| ▪ Ukuran - Berat |
: 175 x 88 x 59mm - 160gr. |
|
| |
|
|
| c. pH/Suhu |
|
|
| ▪ pH Accuracy |
: ±0.002 pH |
|
| ▪ Temp. Accuracy |
: ±0,5°C |
|
| ▪ Memory |
: 500 data set with date/time |
| ▪ Output |
: USB Communication interface |
| ▪ Power |
: 3x1.5V "AA" battery |
|
| |
|
|
| d. BOD |
|
|
| ▪ Satuan ukur |
: mg/l |
|
| ▪ Botol |
: 6 buah, Warna Gelap |
|
| ▪ BOD pembacaan |
: Pembacaan 0-40 |
|
| ▪ Pressure range |
: 500-1350 hPa |
|
| ▪ Tenaga |
: Lithium Battre |
|
| |
|
|
| e. TSS |
|
|
| ▪ Panjang gelombang |
: 880 nm |
|
| ▪ Waktu pembacaan |
: 0,5 detik |
|
| ▪ Pengoperasian alat |
: 4 tombol |
|
| ▪ Satuan ukuran |
: mg/l, g/l, ppm |
|
| ▪ Panjang Kabel |
: 5 meter |
|
| |
|
|
| f. Alat uji Bau |
|
|
| ▪ Metode Pembacaan |
: Gas Sensor 2 semiconduktor |
| ▪ Sampel Metode |
: Dengan Mengisap udara |
|
| ▪ Sasaran pengukuran |
: Ethanol, Acetone, Hydrogen |
| ▪ Memori |
: 0 ~ 32,732 Data |
|
| ▪ Koneksi komputer |
: USB cable |
|
| ▪ Tenaga |
: Battre 4 x AAA (alkaline battre) |
| |
|
|
| g. Alat ukur aliran Air (current meter) |
|
| ▪ Kemampuan ukur |
: 0,5 - 2,5 m/detik |
|
| ▪ Akurasi |
: ± 5% |
|
| ▪ Tipe Sensor |
: Baling-baling (3 bagian Stik ) |
| ▪ Koneksi Data |
: Kabel USB transfer data ke komputer |
| ▪ Batterei |
: 9 Volt |
|
| |
|
|
| h. Alat inkubasi |
|
|
| ▪ Rak |
: 2 tingkat |
|
| ▪ Temperature |
: 3 to 50°C |
|
| ▪ Kapasitas |
: 120 ltr |
|
| ▪ Display |
: LCD 3 Digit |
|
| ▪ Power |
: 220V 50/60 Hz |
|
| |
|
|
| i. Thermoreactor |
|
|
| ▪ Reactor type |
: Dry temperature control device |
| ▪ Number of vial cells |
: 16 cells shafts for reaction cell |
| |
16mm ±0.2mm |
|
| ▪ Temperature setting |
: 100˚C, 120˚C, 150˚C, programs, |
| |
and 50˚C to 199˚C user setting |
| ▪ Controlling accuracy |
: ±1˚C(±1 digit) |
|
| ▪ Temperature stability |
: ±1˚C |
|
| ▪ Heating from 25˚C to |
: 25°C to 100˚C approx. 5 min. |
| |
: 25°C to 120˚C approx. 6 min. |
| |
: 25°C to 150˚C approx.9 min. |
| |
: 25°C to 165˚C approx.11 min. |
| |
: 25°C to 199˚C approx. 15 min. |
| ▪ Programmable Temp. |
: 50˚C to 199˚C |
|
| ▪ Programmable time |
: 0-18 hours, Audio signal and heating |
| |
stopped when the time expired |
| ▪ Temp. Correction |
: ±9˚C adjustment for thermoblock |
| ▪ Ambient temperature |
: 10~50˚C |
|
| ▪ Overheating protector |
: Yes |
|
| ▪ Power supply |
: 220 VAC ±10%, 50/60 Hz |
|
| |
|
|
| j. Carrying case |
: For COD Photometer, pH, TSS |
| |
|
|
| k. Glass cuve |
: 4 x 24mm / 10ml |
|
| |
|
|
| l. Cleanig tool |
: Stirring rod Cleaning brush |
|
| |
|
|
| m. Transfer data |
: Bluetooth USB dongle |
|
